Getriebe
56JMS
Planetary gearboxes - JMS series
| Length (L) (mm) |
37,8 - 60,8 |
| Reduction Ratio |
3,6 - 76,77 |
| Nominal Output Torque (Nm) |
9 -30 |
GP56 -S
Planetary gearboxes - GP series
| Length (L) (mm) |
50,6 - 67,8 |
| Reduction Ratio |
3,293 - 62,326 |
| Nominal Output Torque (Nm) |
7,73 - 26,48 |
| Max. Input Speed (rpm) |
4658 - 13000 |
GP56 -N - Low noise
Planetary gearboxes - GP series
| Reduction Ratio |
3,24 - 35,05 |
| Nominal Output Torque (Nm) |
1,53 - 15,84 |
| Max. Input Speed (rpm) |
5450 - 9758 |
GP56 -T - Torque
Planetary gearboxes - GP series
| Length (L) (mm) |
54,8 - 86 |
| Reduction Ratio |
3,293 - 256,23 |
| Nominal Output Torque (Nm) |
7,73 - 35 |
| Max. Input Speed (rpm) |
4658 - 13000 |
GWS
Worm & wheel gearboxes
| Nominal Output Torque (Nm) |
2 - 4,5 |
| Max. Output Torque (Nm) |
3,2 - 7,2 |
GW58
Worm & wheel gearboxes
| Nominal Output Torque (Nm) |
4 |
| Max. Output Torque (Nm) |
8 |
GW80
Worm & wheel gearboxes
| Nominal Output Torque (Nm) |
5 - 12 |
| Max. Output Torque (Nm) |
8 - 19 |
GW12
Worm & wheel gearboxes
| Reduction Ratio |
12,5 - 75 |
| Nominal Output Torque (Nm) |
18 - 30 |
| Max. Output Torque (Nm) |
29 - 48 |
GWL
Worm & wheel gearboxes
| Nominal Output Torque (Nm) |
15 - 19 |
| Max. Output Torque (Nm) |
15 - 22 |
GW65
Worm & wheel gearboxes
| Nominal Output Torque (Nm) |
120 |
| Max. Output Torque (Nm) |
300 |
Motor Steuerungen/Controller
Scorpius
BLAC motor Controllers
| Interface |
Modbus-RTU, CANopen, EtherCAT |
| Power Supply |
100 - 240 VAC |
| Phase Current up to (A rms) |
3 |
| Motor Power up to (W) |
750 |
Serpens
BLAC motor Controllers
| Interface |
ModbusRTU, CANopen, ModbusTCP, EtherCAT, Profinet |
| Power Supply |
85 - 265 VAC |
| Phase Current up to (A rms) |
5,2 |
| Motor Power up to (W) |
1300 |
